Safetron Engine lock 5250 cpl

SAFETRON motor lock 5250 in set packaging. The kit package contains: motor lock 5250, control unit 5000, connection cable C01 (10m), end plate 106-2 and frame transfer CT81.

SAFETRON 5250 disarms in 0.3 seconds and therefore no separate day lock is normally needed on high-frequency doors.

Typical areas of use are day, night and security locking in commerce, offices and industry. The lock meets requirements corresponding to SS 3079 lock class 3. The motor lock is equipped with a reinforced straight piston for maximum strength.

• Mandrel depth: 50 mm

• Straightening piston

• Fall piston

• Disarms for 0.3 seconds

• Adapted for door automation

• Certified according to SS-EN 14846

The control unit has double terminal rows (NC/NO) and the following relay function:

• Potential-free opening impulse

• Timer/emergency opening

• External door magnet

• Alarm

• Door closed

• Rule out

• Setting opening time 1-25 s

• Alarm in case of cable loss

• Opening impulse voltage

• Day blocking

• Door open

• Alarm knob function

• Rule inside

• Impulse signal

• Voltage: 10-35 VDC/ 8-24 VAC

• Current consumption: 50-350 mA
