CARD READER LOCK 1189

Contactless card reader with built-in electric lock.

Without hole for lock cylinder. The Låsa 1179 door leaf reader has a built-in electric push lock and contactless reader in the same product.

Made of stainless steel and matt brushed chrome and intended for mounting on door leaves without a lock cylinder with built-in buzzer.

Split mounting means that the reader is protected on the inside of the door, with only the antenna and indication on the outside.

Replace the current lock housing with the electric push lock, ABLOY EL980, which is included in the product.

Reads contactless cards or keys for EM and is made for outdoor and indoor installation.

Power supply V DC: 12- 24 supplied by the central unit

Consumption Amp A: min 1.3 max 8.0Amp: min 0.11 max 0.66

Temperature inside °C: 0 to +40 Humidity inside %: 10 to 90 Temperature outside °C: -30 to +60

Humidity outside %: 10 to 100

Central units with manual programming AC 280: NoAC 360: No

Central units with programming via PC 500 XX: No600 XX: No700 XX: YesMC1: Yes
