Emergency opener Type T for split spindle lock - For Abloy EL580 - Safetron SL520, SL620 and Step: 110, 120
Emergency opener Type T is a robust and reliable solution for split spindle locks, including Abloy EL580 and Safetron SL520. Simple installation and high security for reliable emergency exit solution.
Emergency Opener Type T for Split Spindle Locks - Safe and Reliable Emergency Exit Solution
Emergency opener Type T is a high-quality and reliable solution for split spindle locks. It is designed to ensure that doors can be opened quickly and easily in emergency situations. When ordering, state which lock box you have to ensure compatibility.
Features and Benefits
Compatibility: Specially designed for split spindle locks, including Abloy EL580 and Safetron SL520.
Robust construction: Made to withstand demanding environments and ensure long-term use.
Easy Installation: Clear assembly instructions for quick and easy installation.
High Security: Locking function that prevents unauthorized manipulation and ensures that the emergency opener works reliably when needed.
Flexible Use: Adapted for both right- and left-hung doors without the need for modification.
Technical Specifications
Fits the following lock types:
Abloy: EL580
Safetron: SL520, SL620
Step: 110, 120
Material: Robust and durable to ensure long-term use.
Installation: Easy to install with included assembly instructions and accessories.
Dimensions: Adapted for standard doors.
Assembly instructions
Preparation: Open the door with the existing knob or push and check that the door and lock work smoothly.
Mount Bringer: Remove the knob or pressure, mark a center line and replace the existing driver with the one provided.
Assemble the Mechanism: Insert the square pin into the lock's driver and connect the bottom plate with the outer sleeve.
Adjust and Attach: Cut the square pin according to the sketch, attach the outer sleeve with the cylinder ring of the lock and adjust the bottom plate.
Final assembly: Attach the trailing arm, adjust the upper attachment arm and check that everything is working correctly.
Control and Maintenance
Function test: After installation, perform an ocular check and a simplified functional check to ensure that the emergency opener is working properly.
Annual Control: Carry out an annual check to ensure that all components are in good condition and that the emergency opener is working properly.
