Optex FMX-DT – Dual-Tech motion detector for demanding indoor environments

Optex FMX-DT is a professional dual technology motion detector for indoor use, developed to provide maximum security even in environments where traditional sensors risk false alarms. By combining PIR (passive infrared) with microwave technology, it requires both technologies to detect motion simultaneously for an alarm to be triggered – a method that drastically reduces the risk of false alarms.

The detector covers up to 15 meters in width with an 85° angle and has a intelligent digital analysis logic (SMDA) which adjusts sensitivity to temperature and environmental disturbances. It is also pet-resistant, making it suitable for homes with pets.

FMX-DT is particularly effective in spaces where there is heat exchange, drafts, bright light or electronics, as in garages, entrance halls, basements and technical rooms.

Advantages:

• Dual technology (PIR + Microwave) for minimal false alarms

• Animal-resistant – specially adapted for home environments with pets

• SMDA logic – adjusts sensitivity and enhances reliability

• Temperature compensation – stable function regardless of the season

• LED indicator – selectable display in case of alarm

• Simple installation – Plug-in End of Line Unit (PEU) support

Technical specification:

• Technique: PIR + Microwave (Dual-Tech)

• Coverage: 15 m x 15 m (85°)

• Zones: 78 (via PIR)

• Mounting height: 2.2 – 3.0m

• Power consumption: approx. 17 mA at 12 VDC

• Temperature range: -20°C to +50°C

• Measure: 111.7 x 61.4 x 50.0mm

• Weight: about 100g

• LEDs: On/off via jumper

• PEU compatible: Yes (for easy connection to alarm centers)

Ideal for:

• Garage, basement and technical room

• Entrance halls with drafts or sunlight

• Villas with tough indoor environments

• Business premises where high security is required

Upgrade your indoor protection with Optex FMX-DT – a safe and intelligent sensor that provides peace of mind even in the most challenging environments.
