Electric end plate 5114 Reverse 24V Piston contact

Electric strike 5114 Reverse 24V with piston contact, for doors with low security requirements in retail, offices and industry. Unlocked in case of power failure, breaking strength 400 kg.

Electric Strike 5114 Reverse 24V Piston Contact is an electric strike that is perfect for doors with low security requirements, making it ideal for use in commerce, offices, and industry.

It is well suited for internal locking, where a reliable and cost-effective locking system is a requirement but where security does not need to be as strict as in more exposed environments.

This electric strike has a reverse function, meaning that the door is unlocked in the event of a power failure. This makes it a practical solution in situations where the door needs to be unlocked in the event of a power failure.

The electric strike is made with a steel pivot and a zinc alloy lock housing, making it a robust and durable product that can withstand long-term use.

With a breaking strength of 4000 N (400 kg), it is strong enough for use in many doors that require reliable locking.

Electric strike 5114 Reverse 24V Plunger contact can be used in combination with single or double latch locks, and it can also be supplied with a microswitch and locking plunger contact, making it possible to integrate it into an automated locking system or with other security solutions.

Key Features and Benefits:

• Reverse function: Unlocked in the event of a power failure for flexible use.

• Breaking strength: Holds up to 4000 N (400 kg) for reliable locking.

• Steel torsion bar: Durable and wear-resistant construction for long service life.

• Compatibility: Suitable for use with single or double-leaf locks.

• Can be supplied with microswitch and locking plunger contact: To increase flexibility and safety in the installation.

• Not for fire compartment doors: Not suitable for use in fire compartment doors.

Technical Specifications:

• Voltage: 24VDC ±10%

• Current consumption: 0-110 mA

• Breaking strength max: 4000 N (400 kg)

• Torsion: Steel

• Lock body: Zinc alloy

• Operating voltage: 24 VDC

• Piston contact: Yes

• Protective diode: It is recommended to use a protective diode near the electric strike coil to protect the electronics.
